1.Interlocking door with auto-shutdown protection device;
2.Optional rotary attachment for round bottles engraving;
3.Red Cross accurate positioning, convenient and quick in finding working position. Three-mirrors and one focal lens path system to deliver outstanding finishing effect;
4.Equipped with manual focused laser head, flexible and accurate, the machine can adjust the focus position according to engraving and cutting.


Model
HL1006X       HL1309X
Working Area
1000*600mm   1300*900mm
Laser Output Power
80w/100w/120w/150w/180w
Engraving Speed
0-20000mm/min

Product advantages



RD control system




RECI laser tube

The product is featured for working under large power rate and long service time, high efficiency,narrow mark line,deep scale, high resolution.


Stepper motor
Low Noise
Low Vibration
Smooth Operation
High Torque
Higher Acceleration Ability
Better Precision
Better Acceleration Performance
3 Phase NEMA 42 stepper Motor



Germany Linear Guide Rail

Adopted Germany BOBO linear guide rail, high positioning accuracy, scroll guide, reduce wear to maintain accuracy for a longer time.


WIFI Control

Convenient- Engineers can remotely control computers and machines, adjust parameters and solve problems.Efficiency- One PC can control several machines.


Technical Parameters

Model
HL1006X
HL1309X
Working Area
1000*600mm
1300*900mm
Laser Power
80W/100w/120w/150w
Laser Type
CO2 Sealed Laser Tube ,10.6μm
Cooling Type
Water Cooling
Engraving Speed
Water Cooling
Cutting Speed
0-40000mm/min
Laser Output Control
0-100% set by software
Min. Engraving Size
Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm
Highest Scanning Precision
4000DPI
Locating Accuracy
≤+0.01mm
Controlling Software
RD Control System
Graphic Format Supported
DST PLT BMP DXF DWG AI LAS,etc
Compatible Software
CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc.
Color Separation
Yes
Drive System
High-precision 3-phase Stepper Motor
Auxiliary Equipments
Exhaust Fan and Air Exhaust Pipe
power Supply
AC110V/220V+10%,50HZ/60HZ
Working Environment
Temperature:0-45C,Humidity 5-95%(No Condensate Water)
