1.Mini Size ,Easy operation,electric up and down table , facilitated with ball screw transmission system,capable of processing non-metal material.
2.Interlocking door with auto-shutdown protection device;
3.cutting edge is smooth without ripples;

Product advantages

RD control system



RECI laser tube

The product is featured for working under large power rate and long service time, high efficiency,narrow mark line,deep scale, high resolution.

Stepper motor
Low Noise
Low Vibration
Smooth Operation
High Torque
Higher Acceleration Ability
Better Precision
Better Acceleration Performance
3 Phase NEMA 42 stepper Motor



Germany  Linear Guide Rail

Adopted Germany BOBO linear guide rail, high positioning accuracy, scroll guide, reduce wear to maintain accuracy for a longer time.



WIFI Control

Convenient- Engineers can remotely control computers and machines, adjust parameters and solve problems.
Efficiency- One PC can control several machines.


Technical Parameters

Model
HL0503MU
HL0605MU
Working Area
500*300mm
600*500mm
Laser Power
40W
40W/80W
Laser Type
CO2 Sealed Laser Tube, 10.6μm
Cooling Type
Water Cooling
Engraving Speed
0-60000mm/min
Cutting Speed
0-40000mm/min
Laser Output Control
(0-100% Set by Software )
Min. Engraving Size
Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm
Highest Scanning Precision
4000DPI
Locating Precision
≤+0.01mm
Controlling Software
RD Control System
Graphic Format Supported
DST PLT BMP DXF DWG AI LAS,etc
Compatible Software
TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,etc
Color Separation
Yes
Drive System
High-precision 3-phase Stepper Motor
Auxiliary Equipments
Exhaust Fan and Air Exhaust Pipe
power Supply
AC110V/220V+10%,50HZ/60HZ
Working Environment
Temperature:0-45℃,Humidity 5-95%(No Condensate Water)
Optional Spare Parts
Honeycomb Worktable, Rotary Device,Auto-focus Device
