Product advantages



RD control system

RECI laser tube

The product is featured for working under large power rate and long service time, high efficiency,narrow mark line,deep scale, high resolution.

Stepper motor
Low Noise
Low Vibration
Smooth Operation
High Torque
Higher Acceleration Ability
Better Precision
Better Acceleration Performance
3 Phase NEMA 42 stepper Motor



Germany Linear Guide Rail

Adopted Germany BOBO linear guide rail, high positioning accuracy, scroll guide, reduce wear to maintain accuracy for a longer time.



WIFI Control

Convenient- Engineers can remotely control computers and machines, adjust parameters and solve problems.
Efficiency- One PC can control several machines.


Technical Parameters

Model
HL1325B
HL1630B
HL2030B
Working Area
1300*2500mm
1600*3000mm
2000*3000mm
Laser Power
80W/100w/120w/150w
Laser Type
Sealed Co2 Laser Tube,10.6μm
Cooling Type
Water Cooling
Cutting Speed
0—30000mm/min
Laser Output Control
0—100% Software Setting
Highest Scanning Precision
4000DPI
Locating Precision
≤+0.01mm
Color Separation
Yes
Drive System
High-precision 3-phase Stepper Motor
Auxiliary Equipments
Exhaust Fan and Air Exhaust Pipe
Power Supply
AC110V/220V+10%,50HZ/60HZ
Option
Honeycomb Worktable
